Product description
The direct-coupled motor series is a product specially developed by our company for the reducer market. We can customize connecting flanges and output shafts of different sizes according to customer needs. It has the characteristics of low oil leakage rate, low vibration, low noise, high efficiency, compact and beautiful structure.
Product related parameters

Main specifications

Product description
YD series two-speed motors use variable stator windings to change the number of motor poles to achieve variable speed. The motor has the characteristics of varying the power and speed stepwise according to the different requirements of the load, so as to achieve a reasonable match with the load, which is of great significance to simplify the transmission system and save energy. Therefore, it is widely used in various transmission mechanisms that require stepwise speed regulation.
Product related parameters

Main specifications

The IE4 motor series synchronous reluctance motor is a fully enclosed, self-fan air-cooled super high-efficiency (IE4) three-phase synchronous reluctance motor designed and manufactured using new electromagnetic design technology, new technology, and new materials.
IE4 motor series synchronous reluctance motors have the characteristics of high efficiency, large starting torque, wide speed range, high steady-state accuracy, and low noise and vibration. There is no magnetic steel inside the motor (no permanent magnet, different from permanent magnet synchronous motor), there is no risk of demagnetization, and it is stable and reliable. It can be used to drive plastic machinery, machine tool spindles, textile machinery, pharmaceutical machinery, air compressors and other light industrial machinery needs, as well as petroleum, chemical, and paper machinery.

Product description
YBBP series frequency conversion explosion-proof motor is a new product successfully developed on the basis of YB3 series motor combined with current new technologies in electromagnetic structure, process, material, etc. at home and abroad. It has good speed regulation performance, energy saving, large temperature rise margin, It has the advantages of long life, good performance, low noise, advanced flameproof structure, high reliability, convenient use and maintenance, etc. It can be used with various frequency conversion devices at home and abroad, which is helpful for energy saving and automatic control. Its rated power, rated speed and installation dimensions are the same as YB3 series explosion-proof motors. The frequency conversion explosion-proof motor conforms to the industry standard JB / T7565.1-2004 “YB3 series flameproof three-phase asynchronous motor technical conditions (frame number H100-355)” of GB755-2000 “Quota and Performance of Rotating Motors”. Its explosion-proof performance meets the requirements of GB3836.1-2000 “Electrical Equipment for Explosive Gas Environment Part 1: General Requirements” and GB3836.2-2000 “Electrical Equipment for Explosive Gas Environment Part 2: Flameproof Type” d “”, They are made into explosion-proof ExdI, ExdIIAT4, and ExdIIBT4 respectively, which are suitable for the dangerous places in underground coal mines (non-excavation face) and the explosive gas environment of Group IIA and IIB, temperature group T1 ~ T4. The protection grade of the inverter explosion-proof motor is IP54 or IP55, and the cooling method is IC416. Inverter explosion-proof motors can also be made into humid tropical type, dry tropical type, outdoor type and outdoor anti-medium corrosion type and outdoor humid heat type.
Product related parameters

Main specifications

Product description
YB3 series high-efficiency flameproof three-phase asynchronous motor is a fully enclosed, self-fan cooling high-efficiency motor. This series of products replaces the original YB2 series flameproof three-phase asynchronous motor, and its efficiency meets the requirements of GB18613-2012 energy efficiency level 3 standard. The explosion-proof performance of YB3 series motors is in accordance with GB3836.1-2010 “Electrical Equipment for Explosive Gas Environment Part 1: General Requirements” and GB3836.2-2010 “Electrical Equipment for Explosive Gas Environment Part 2: Explosion-proof Type” d “” Regulations, applicable places: ExdⅡBT4Gb is suitable for the environment where the factory uses Class II Class B, temperature group is T4 group explosive gas mixture.
Product related parameters

Main specifications

Product description
YPEJ series frequency conversion brake motors are three-phase asynchronous motors with fully enclosed external reinforced chillers and additional disk-type DC brakes. It has the advantages of wide frequency modulation range, rapid braking, simple structure, high reliability and strong versatility. In addition, the brake has a manual release mechanism, which is widely used in various mechanical equipment that needs speed regulation and rapid stop, accurate positioning, reciprocating start, frequent start, and prevention of sliding as the main drive and auxiliary drive. For example, it is used in the lifting of transportation machinery and the dragging of walking machinery, the dragging of various metal cutting machine tools, printing machines, forging machines, cement mixers, woodworking machinery, papermaking machinery, rubber and plastic machinery and textile machinery.
Product related parameters

Main specifications

Product description
YVP series frequency conversion motors are fully enclosed, external fan cooled, squirrel cage three-phase asynchronous motors. This series of motors are optimized by computer-aided optimization and are more suitable for PWM frequency conversion power supply drive. To solve the problem of low-frequency motor temperature rise, the motors are The fan is forced air-cooled, the fan is connected to the power supply to operate, the motor can achieve very smooth stepless speed regulation under the drive of the frequency converter, and the speed regulation range is wide, which can be widely used in applications requiring low frequency constant torque (5-50Hz), high frequency constant Various transmission machinery with power (50-100Hz) has a wide range of energy-saving effects.
Product related parameters

Main specifications

Product description
YEJ series electromagnetic brake motors meet the requirements of national standard JB / T6456, and the electrical performance meets the technical standards of YE2 series motors. An electromagnetic brake is installed at the tail end of the motor. When the motor is de-energized, the brake disc of the electromagnetic plane actuator automatically presses against the back cover of the motor to generate a friction braking torque, which causes the motor to stop instantly. The no-load braking time is random. Small to large, 0.15 ～ 0.45S. The power supply of the brake must use power frequency power supply.
Product related parameters

Main specifications

Product description
YE3 series three-phase asynchronous motors comply with the secondary efficiency standards specified in GB18613-2012 “Limited Values and Levels of Energy Efficiency of Small and Medium-sized Three-phase Asynchronous Motors” and the IE3 energy efficiency level of the IEC60034-30-2008 standard. The use environment is the same as that of YE2 series high-efficiency motors, with higher efficiency, which is the first choice for energy-saving and environmental protection transformation.
Product related parameters

Main specifications
